📐 SPECIFICATIONS

Technical Details & Standards

All measurements according to Indian room sizes and TV standards

Standard Widths

Compact: 4-5 feet (120-150 cm)
For 32"-43" TVs, 1BHK apartments

Medium: 5-6.5 feet (150-200 cm)
For 43"-55" TVs, 2BHK living rooms

Large: 7-10 feet (210-300 cm)
For 55"-85" TVs, 3BHK+ homes

Heights

Low Profile: 18-24 inches (45-60 cm)
Minimalist, modern look

Standard: 24-36 inches (60-90 cm)
Most popular choice

Tall Unit: 60-84 inches (150-210 cm)
Full wall entertainment centers

Depth

Wall Mounted: 12-15 inches (30-38 cm)
Space-saving design

Floor Standing: 16-20 inches (40-50 cm)
Standard depth for storage

With Swing Doors: 18-22 inches (45-55 cm)
Extra depth for door clearance

TV Size Guide

32" TV: Unit width 3.5-4 feet minimum
Viewing distance: 4-5 feet

43"-50" TV: Unit width 4.5-5.5 feet
Viewing distance: 5.5-7 feet

55"-65" TV: Unit width 6-8 feet
Viewing distance: 7-9 feet

Storage Dimensions

Drawer Height: 6-10 inches each
Ideal for remotes, cables, DVDs

Open Shelf: 12-16 inches height
For set-top box, soundbar

Cabinet Depth: 14-18 inches
For books, decoratives

Load Capacity

TV Panel Support: 60-100 kg
Handles all TV sizes safely

Shelf Load: 20-30 kg per shelf
For electronics & decoratives

Drawer Load: 15-20 kg
For DVDs, media accessories

Plywood Options

Commercial Ply (BWP):
710 Caliber, ₹75-85/sq.ft
Boiling water proof, budget-friendly

BWR Plywood:
Century, Greenply ₹95-110/sq.ft
Water resistant, durable

Marine Ply:
Premium quality, ₹140-160/sq.ft
Maximum durability

Board Materials

MDF Board:
High density, smooth finish
6mm to 25mm thickness

HDF Board:
Extra strong for doors
Resists warping

Particle Board:
Budget option with laminate
Suitable for shutters

Surface Finishes

Laminate:
Merino, Greenlam, Sundek
1mm thick, wide range

Veneer:
Natural wood finish
Walnut, oak, teak options

PU Finish:
Glossy, semi-gloss, matte
Premium look, easy to clean

Edge Banding

PVC Edge Band:
0.5mm to 2mm thick
Color matching available

ABS Edge Band:
Premium quality
Impact resistant

Veneer Edge:
For veneer finishes
Seamless look

Hinges

Hettich/Ebco/Hafele:
Soft-close hydraulic hinges
110° opening angle
15-20 years warranty

Load Capacity:
Up to 40kg per pair
Adjustable in 3 dimensions

Drawer Channels

Telescopic Channels:
Hettich/Ebco brand
Soft-close/push-to-open
45cm to 60cm length

Full Extension:
100% drawer access
Load capacity: 25-35kg

Handles & Knobs

Aluminum Handles:
Sleek C-channel design
160mm to 1000mm length

Profile Handles:
Integrated, handleless look
Modern aesthetic

Brass Knobs:
Traditional/luxury look
Various finishes available

Cable Management

Grommet Holes:
50-80mm dia cutouts
Plastic/metal grommets

Cable Trays:
Behind-unit organization
Wire mesh trays

Power Sockets:
Integrated socket panels
5-6 socket provision

LED Lighting

LED Strips:
12V/24V options
Warm white/cool white
Remote controlled RGB

Installation:
Behind TV backlight
Under shelf lighting
Display cabinet lights

Wall Mounting

Wall Brackets:
Heavy-duty L-brackets
Stainless steel, rust-proof

French Cleats:
For wall panels
Easy install/remove

Rawl Plugs:
10mm x 50mm for concrete
Load tested mounting

Laminate Finishes

Solid Colors:
White, black, grey shades
Glossy/matte finish

Wood Textures:
Walnut, oak, teak, wenge
Natural grain patterns

High Gloss:
Mirror-like finish
Modern, contemporary look

Veneer Options

Natural Veneer:
Teak, walnut, oak
0.6mm thickness

Engineered Veneer:
Consistent patterns
Cost-effective

Finish Coating:
PU polish (4-6 coats)
Protects & enhances grain

Acrylic Finishes

High Gloss Acrylic:
1mm thick acrylic sheet
UV protected, non-yellowing

Available Colors:
40+ color options
Custom colors possible

Durability:
Scratch resistant
Easy to clean, long-lasting

Glass Options

Back-Painted Glass:
8mm thick toughened
Any color painting

Frosted Glass:
For display cabinets
Sandblasted finish

Clear Glass:
Shelves & doors
LED lighting ready

📏 SIZE GUIDE

Choose the Right Size

Based on your TV size and room dimensions

Compact Units

Dimensions: 4-5 feet W × 18-24" H

TV Size: 32"-43"

Room Type: 1BHK, Bedroom

Viewing Distance: 4-6 feet

Perfect for small apartments, bedrooms, or secondary viewing areas.

Standard Units

Dimensions: 5-7 feet W × 24-36" H

TV Size: 43"-55"

Room Type: 2-3BHK Living Room

Viewing Distance: 6-8 feet

Most popular choice for Indian living rooms. Ample storage included.

Premium Units

Dimensions: 7-12 feet W × 60-84" H

TV Size: 55"-85"

Room Type: 3BHK+ / Villa

Viewing Distance: 8-12 feet

Full wall entertainment centers with maximum storage and display.

✨ SMART FEATURES

Modern TV Unit Features

Designed for today's smart homes

Integrated Cable Management

Hidden cable trays and grommets keep wires organized. Provision for power sockets behind the unit. Clean, clutter-free appearance.

LED Strip Lighting

Backlit TV panel creates ambient lighting. RGB LED strips with remote control. Energy-efficient 12V/24V systems.

Smart Storage Solutions

Dedicated compartments for set-top boxes, gaming consoles, and DVDs. Soft-close drawers for remotes and accessories. Open shelving for soundbars.

Ventilation Holes

Back panel ventilation prevents electronic overheating. Side vents for better airflow. Keeps devices running cool.

Customizable Design

Choose from 500+ laminate colors and textures. Mix-match finishes for unique look. Match existing home decor perfectly.

Sturdy Construction

Load-tested to hold 60-100kg TV weight. Heavy-duty wall mounting brackets. 10-year structural warranty on plywood.

Premium TV Units & Entertainment Centers

All TV Sizes

Custom Sizes

Smart Storage

Quick Install

TV Unit Styles

Wall Mounted Unit

Floor Standing Unit

Full Wall Entertainment Center
